30FT Expandable Container House with 56㎡ Dual Side Fold-Out Galvanized Steel Prefab Home

Tên thương hiệu:	SUNHOUSE
MOQ:	1
Giá:	Có thể thương lượng
Điều khoản thanh toán:	T/T

Thông tin chi tiết

Mô tả sản phẩm

Thông tin chi tiết

Nguồn gốc:

Quảng Đông

Chứng nhận:

Đặc điểm kỹ thuật:

30FT

Kích thước mở rộng:

9000X6220X2480

MOQ:

1 đơn vị

Sử dụng:

Nhà/Văn phòng/Cửa hàng/Nhà vệ sinh/Biệt thự/Kho

Khu vực:

56m2

sống thoải mái:

Miễn phí kết hợp 1-4 phòng ngủ, phòng tắm và nhà bếp. Thiết kế linh hoạt với việc sử dụng 100% không

Tùy chọn nội thất:

Nhà bếp và phòng tắm

Loại sản phẩm:

Vùng chứa có thể mở rộng

Mô tả sản phẩm

30FT Expandable Container House | 56㎡ Dual Side Fold-Out Galvanized Steel Prefab Home

This innovative 30FT expandable container house offers an optimal balance of compact transport size and generous living space. In its folded state, it measures just 9,000 × 2,200 × 2,480 mm, allowing standard road transport without special permits. Once on site, the dual-side bilateral expansion system unfolds rapidly to create a spacious 56㎡ interior — perfect for comfortable one-bedroom living, efficient site offices, or multi-bed worker accommodation. Built with a robust hot-dip galvanized Q345B steel frame and high-performance insulated sandwich panels, the unit provides excellent structural integrity, weather resistance, and energy efficiency for various global project environments.

Why the 30FT Expandable Model Delivers Maximum Value At 56㎡ expanded floor area and only 4.25 tons, this model strikes the perfect balance between usable space and logistical ease. It ships as one unit per 40HQ container, significantly lowering freight costs while providing enough room for most single-family, small team, or workforce housing needs — without the higher weight and transport challenges of larger 40FT models.

Key Features

Expands from compact transport size to a full 56㎡ living space
Dual-side bilateral fold-out mechanism for fast and stable expansion
Heavy-duty hot-dip galvanized Q345B steel frame for superior strength and corrosion protection
Tool-free mechanical locking system secures expanded wings safely
High-density insulated sandwich panels (EPS, rock wool, or PU options)
Advanced TPO waterproof roof membrane for long-term weatherproofing

Double-glazed aluminum sliding windows with integrated insect screens
Insulated steel entry door with multi-point security locking system
Durable moisture-resistant plywood floor with modern SPC vinyl finish
Factory pre-installed electrical conduits, distribution board, and LED lighting
Pre-plumbed stub-outs ready for quick bathroom and kitchen connection
Heavy-duty adjustable leveling feet for stable installation on uneven terrain

Technical Specifications

Product Type	30FT Dual-Side Expandable Container House
Expanded Dimensions (External)	9,000 mm (L) × 6,220 mm (W) × 2,480 mm (H)
Internal Dimensions (Expanded)	8,540 mm (L) × 6,060 mm (W) × 2,240 mm (H)
Folded Transport Dimensions	9,000 mm (L) × 2,200 mm (W) × 2,480 mm (H)
Expanded Floor Area	56 m²
Expansion Mechanism	Dual-side bilateral fold-out with mechanical safety locks
Main Frame Material	Q345B hot-dip galvanized structural steel
Wall Panel Options	100mm EPS / 150mm Rock Wool / 75mm PU sandwich panels
Roof System	100mm insulated sandwich panel + 1.2mm TPO waterproof membrane
Floor Construction	18mm moisture-proof plywood + 3mm SPC vinyl plank flooring
Windows	Aluminum alloy double-glazed sliding windows with mosquito screens
Entry Door	50mm insulated steel door with multi-point locking system
Electrical System	220V pre-wired conduit, distribution board, LED lights & power outlets
Plumbing Preparation	PPR supply lines and PVC drainage stubs for bathroom & kitchen
Wind Resistance	Up to 120 km/h (Level 10)
Snow Load Capacity	0.5 kN/m²
Unit Weight	4.25 tons
Loading Capacity (40HQ)	1 unit (in folded state)
Installation Time	60–90 minutes by 2 workers (no crane required)
Expected Service Life	20+ years with proper maintenance
Customization Options	Full OEM/ODM support including layout, insulation type, colors, and fit-outs

Applications

One-bedroom residential units for rural housing and affordable living projects
Compact site offices and project management centers for construction teams
Worker dormitories and camp accommodation for mining and infrastructure sites
Premium glamping cabins and eco-tourism accommodation
Temporary medical clinics and healthcare outreach stations
Mobile classrooms and vocational training facilities
Security posts, guard houses, and border control units
Emergency relief shelters and disaster recovery housing solutions

Frequently Asked Questions

What makes the 30FT expandable container house more practical than 20FT or 40FT models?

The 30FT model provides 56㎡ of usable space — significantly more than the 20FT — while remaining lightweight at 4.25 tons for easy road transport. It offers better cost-efficiency and site flexibility than the larger 40FT version, making it the ideal choice for most single-unit residential, office, or small-team housing requirements.

Is a crane necessary for unfolding and installing the unit?

No crane is required for the expansion process. The dual-side fold-out system uses simple mechanical locking pins that can be operated manually by just two workers. Only a forklift or small telehandler is needed to unload the unit from the truck and place it on level ground.

What types of interior layouts are possible within the 56㎡ space?

Popular layouts include a full one-bedroom apartment with living room, kitchen, and bathroom; a four-person project office with meeting area; a six-bed dormitory configuration; or a mixed-use office and rest area. We can provide custom floor plans tailored to your exact needs before manufacturing.

Which insulation type is best for different climate conditions?

For hot and tropical regions, 100mm EPS panels with reflective exterior coating work excellently to minimize heat gain. For colder or four-season climates, 150mm rock wool panels are preferred due to their superior thermal insulation, fire resistance, and soundproofing performance.

What information is required for a detailed quotation?

Please specify the destination port, order quantity, preferred wall panel type (EPS/Rock Wool/PU), desired interior layout, local voltage and socket standard, plus any additional requirements such as full bathroom/kitchen modules, air conditioning, or furniture packages.

Model Size Comparison

Specification	700 Mini	10FT	20FT	30FT	40FT
Expanded Dimensions (mm)	5900×4800×2480	2950×6300×2480	5900×6300×2480	9000×6220×2480	11800×6220×2480
Internal Dimensions (mm)	5460×4640×2240	2510×6140×2240	5460×6140×2240	8540×6060×2240	11540×6060×2240
Folded Size (mm)	5900×700×2480	2950×2200×2480	5900×2200×2480	9000×2200×2480	11800×2200×2480
Expanded Floor Area (m²)	27.5	18.5	37	56	73
Net Weight (T)	2.1	1.65	3.12	4.25	5.3
Units per 40HQ	6	4	2	1	1
